Automatic Pneumatic Soil Consolidation test Apparatus With DAQ
- Description:
the product is Automatic Consolidation Test System with English software logger , it can realize data acquistion, data processing,
inquiry and printing , keep updated in the future operation requirement .
- Product Introduction
- Features
- Specification
Model: SH-NJ-STC-1MF-II
Product Name: Automatic Pneumatic Soil Consolidation test Apparatus With DAQ System
Technical Features :
1.The system adopts the principle-subordinate design mode of RS485 , which has the characteristics of long transmission distance and fast feedback speed;
2. it has light weigh , small structure and good sealing , suitable for site use
3. The test process is controlled by microcomputer, which is easy to install and operate;
4. The displacement sensor adopts the latest digital dial indicator displacement sensor, which makes the system measurement more accurate and reliable;
5. It can control multiple consolidation meters at the same time (0-1024);
6. Consolidation container: stainless steel material (copper material can be selected),
sample Dia61.8mm * H.20mm (Dia79.8mm * H.20mm can be selected), matching with permeable stone,
ring knife locating ring, retaining ring, pressure cap and other accessories.
Main Specifications :
|
Model |
SH-NJ-STC-1MF-II |
|
Product Name |
Automatic Consolidation Test Apparatus |
|
Max capacity |
5kN |
|
Response time of air pressure |
<1s |
|
Channel working way |
Each channel works independently, and the leakage of one channel does not affect the operation of other channels; |
|
Working capacity |
The system can continuously apply 0-3200kPa pressure and meet the test requirements of high pressure ( 0-3200kPa), and the accuracy of each level is: ≤ 0.5kPa, ≤ 1kPa, ≤ 2kPa; |
|
Displacement sensor: |
1 measuring range 2.7mm, resolution 0.001mm, accuracy 0.003mm |
|
Material |
stainless steel container (other materials can also be selected). |
|
Instruments |
2-units Automatic working model |
